Viscous Product Filling Machine
- SUS304 stainless steel for the main structure.
- Fill the product into cups.
- The speed: about 0-20cups per minute.
- Specially used for tomato paste or other viscous product.
- E-mail: sales@vortechglobal.com
- Categories: Downstream Filling and Packaging Section, Tomato Processing Machine
- Inquiry Now
Product Details
Accurately fills containers with tomato paste, ensuring the right amount of product is dispensed, even for the thick, viscous consistency of paste, while preventing spillage or wastage.
Process It Belongs To:
- The packaging process, specifically after sterilization and mixing, is used to fill containers or jars with the final tomato paste product.
Related Equipment Before:
- Blends and heats the tomato paste to ensure uniform texture and microbial safety.
- Delivers well-mixed, sterile paste to the filling machine through heated pipelines, preserving temperature and consistency.
Sterilization Equipment
- Kills any remaining microorganisms in the paste to meet food safety standards.
- Ensures that only safe, sterilized paste reaches the filling machine, maintaining product hygiene through the filling stage.
Related Equipment After:
Semi-Auto Capping Machine (optional, if using jars)
- Secures airtight caps onto filled containers.
- Receives the filled, open containers directly from the filling machine for immediate sealing to prevent contamination.
Pouch Forming-Filling-Seaming-Coding Monoblock (if using pouches)
- Seals filled pouches and added batch codes or labels.
- Works in tandem with the filling step when integrated as a monoblock or receives filled pouches for final sealing.
Product Parameter:
| Model | VPFD100-5000 |
| Voltage | AC220V/110V 50-60HZ |
| Power | 40W |
| Filling range | 10-100ml/30-300ml/50-500ml/100-1000ml/500-2500ml/1000-5000ml |
| Production speed | 7-36PCS/MIN Depends on filling volume |
| Air pressure | 0.4-0.6mpa |
| Filling Accuracy | ±1% |
| Required air compressor | ≥3kw 100L |
